Power and delicacy, Versatile, reliable and perfect for any production. B.Master PLUS Make added value the strength of your business. With all the technology Tauro has to offer.
For you, it means dry in complete safety thanks to materials certified for contact with food.
Each of our dryers is unique, handmade to order.
B.Master PLUS meets the needs of small/medium-sized processing companies.
It comes equipped with a standard 5.1 kW electric heat source that can be replaced by a 3.4 kW heating unit (optional), for the drying of delicate products that require lower temperatures, such as medicinal plants.
The electric heating system can be supplemented or replaced with water heating batteries to utilise alternative energy sources.
Also B.Master PLUS is modular structure and therefore expandable with a second drying module for higher productivity.
72 shelves
50x70x1,5 cm
25 square metres
of usable area
5.1 kW three-phase
operating temperature
up to 75°C
8
customisable programmes
3.4 kW single-phase
7.5 kW three-phase
for greater thermal power
Wi-Fi
control system
remote operation
Temperature
operating
up to 90°C
4
internal grids
12/24
box baskets for herbs and
11 or 21 cm plant masses
SHELVES
available with wide mesh
or fine mesh
ANTI-ADHERENTS
sheets, nets and trays
to facilitate the process
Number of compartments: 72 (shelf dimensions 70 x 50 cm)
Total usable surface area: 25 m²
Maximum flow rate: approximately 160 kg
Average daily productivity: 60/100 kg
External dimensions (WxHxD): 190 x 175 x 90 cm
Empty weight: approximately 300 kg
Thermal power: 3.4 kW, 5.1 kW, 7.5 kW;
Electric fan: 450 millimetres
Electric fan power: 80 W.
Temperature regulation: electronics with LED screen.
Regulation of moist air evacuation: manual via wing flap or automatic via channelled extractor
Power supply: 400 V - 50 Hz
Machine made of AISI 430 steel, suitable for contact with food. Baskets made of AISI 304 steel, suitable for contact with food.
B.Master Plus is the highest-performance model in the range, with all our dryers equipped as standard.
Made in Italy
100% stainless steel construction
Electronic temperature control
Heat output: 3.4 kW, 5.1 kW, 7.5 kW; ideal for every requirement
Air exchange control system
The Wi-Fi module allows you to remotely control all the functions of B.Master PLUS from any device: smartphone, tablet, PC or Mac. Start, pause or stop your drying process, manage and monitor temperature and humidity, create and rename your custom programmes.
All from a simple dedicated app. And if there is no network where you work, no problem: B.Master PLUS creates its own Wi-Fi network that you can connect to.
By adding the optional Wi-Fi system, the dryer also gains Industry 4.0 capabilities, allowing it to be interconnected with the company network.
With the Wi-Fi system, you can log the progress of drying cycles and save them for later review, enabling batch tracking over time.
You will have access to additional features not visible from the classic display. A quick guide to what you are viewing and the possibility to create customised recipes more easily.
Entirely made of stainless steel, made with pivoting wheels and designed for quick and easy insertion of drying shelves.
Certified for food contact.
Your best ally for reducing loading and unloading times.
With available heights of 11 and 21 cm, the new herb baskets, completely made of stainless steel and individually handcrafted, allow loads of very voluminous vegetable masses and are compatible at 100% with all B.Master models equipped with standard shelves.
Baskets made of AISI 304 steel, suitable for contact with foodstuffs.
Available in coarse or fine mesh.
Shelves made of AISI 304 stainless steel, suitable for food contact.
Non-stick sheets made of PTFE (Teflon®), suitable for food contact.
Indispensable for drying watery foods, purees, leaves and flowers, sugary and thin products that tend to stick to shelves. Washable and reusable.
Nets made of PP (Polypropylene), suitable for food contact, multi-purpose suitable for sliced products.
They provide non-stickiness and do not obstruct airflow. Two DrySilk Nets can be stacked on top of each other, doubling the capacity of BIOSEC PRO. Washable and reusable.
Exclusive Made in Italy Platinum silicone tray for drying liquid masses.
Ideal for purees, yoghurt, fruit leather and semi-liquid preparations. Washable and reusable.
Whatever brought you to the world of drying, here you’ll find inspiration, ideas, and firsthand experience from those who tried it before you!
B.Master is produced and delivered in a very short time. At specific times of high demand during the year, times may increase slightly. For more precise information, please contact us and request a dedicated quote!
Of course: as per current regulations, the warranty is already active at the time of purchase and offers 12 months' cover for VAT-registered purchases.
B.Master Plus measures 192 cm x 175 cm (H) x 82 cm, weighs approximately 270 kg when empty and has 72 stainless steel shelves inside, providing 25 square metres of drying space.
It depends! It depends on the product, how you prepare it and how you arrange it on the trays. We have created some reference tables that you can find in the catalogue, but to get an exact idea of how much product you can load, arrange the product on a square metre of surface area, just as you would in the dryer. Then multiply the weight of the product arranged by the drying surface area of the machine, in this case 25 square metres.
The power expressed in kW expresses the maximum energy consumption when heating elements and fans are both operating at full capacity. The precise consumption depends mainly on the ambient temperature outside the machine and the amount of total moisture in the product being dried, most of which must be disposed of in the first few hours of drying. Remember that drying is a process that tends towards equilibrium and that, in the very first hours of drying, the aim is to eliminate as much water as possible, especially that present on any wet surface of the product. Moisture is thus disposed of conspicuously at first, then more and more slowly, so the temperature inside the machine will tend to be lower at first, then stabilise. This is why electricity consumption will be much higher at the beginning, and then decrease considerably as time goes by.
The humidity is discharged into the room where you have placed the dryer, which for this reason must be sufficiently large and well ventilated. B.Master Plus can be connected to a humid air disposal pipe if the room where the machine is operating is not large or ventilated enough to accept the moisture extracted from the products, or if the product has a particularly strong or unpleasant odour. If the automatic ventilation module is also purchased, simply connect a round pipe directly to the air outlet.
Yes. If you dry in order to resell the dried product, you will need a dedicated space that complies with European legislation on the safety and hygiene of food processing environments and foodstuffs (EC Regulation 852/2004 at the time of writing) by adopting a control plan according to the H.A.C.C.P. system. This space does not necessarily have to be for the exclusive use of the dryer, but it must still comply with the regulations in force.
No. B.Master Plus is ready to use. Simply remove it from its packaging, place it in the space you have chosen and connect it to the mains. If any components are supplied disassembled for safety reasons during transport, we will enclose all the instructions for assembly, which is a quick and easy operation that does not require any special equipment.
The automatic ventilation module of B.Master Plus has been designed to keep the humidity level inside the dryer under control. The humidity of the product can be measured using special instruments, which vary depending on the type of food being dried.
Yes, it is possible to install a timer as an option. This will only switch off the heating elements, while the internal fan will remain on, both to maintain continuous ventilation inside the dryer and prevent the product from regaining moisture, and as a safety system in case the heating elements do not switch off.
